GOLD MINING RUBBER HOSE

Product Profile

Gold mining rubber hose (also called dredge suction hose or slurry discharge hose) is a large-bore flexible hose built with a highly abrasion-resistant natural rubber (NR/NBR) tube, high-strength tire cord/synthetic fabric plies, an embedded steel wire helix, and a wear-resistant SBR rubber cover. It offers excellent abrasion, vacuum, weather and impact resistance for handling sand, gravel, slurry and ore particles on both pump suction and discharge sides. Working pressure 10 bar, burst pressure 30 bar (3× W.P.), full vacuum rating. Temperature range -20°C to +80°C. Carbon-steel flanges (Q235B painted) fitted at both ends for easy installation. Widely used on gold dredges, river dredging, sand pumping, slurry transfer and municipal desilting. Black is standard and red ends can be made on request . Sizes 3" to 12", with different length on order.

Product Featuresi

1. Highly abrasion-resistant NR/NBR tube — 3-5× longer life than ordinary rubber.

2. Tire cord plies + steel wire helix — vacuum-resistant, no collapse, impact-proof.

3. SBR cover — anti-aging, weather-resistant, cut and abrasion resistant.

4. Carbon-steel flanges at both ends — quick installation, reliable seal.

5. Lighter than steel pipe of same bore, small bending radius — suits complex sites.

6. Absorbs system vibration — protects pumps and equipment.

7. Wide temperature range (-20°C to +80°C) — suits outdoor field work.

8. Customizable colors and lengths.

通用技术规格 / General Specifications
