Product Profile
This series of silent / canopy-type diesel generator sets is driven by a single-cylinder or twin-cylinder direct-injection diesel engine inside a sound-attenuated canopy, covering 3kVA to 12kVA. Built on the open-frame platform, it adds acoustic insulation foam, anti-vibration mounts and a large silencer to greatly cut running noise; the canopy has service doors and movable wheels, with the control panel mounted outside for easy use. It suits home backup, shops, hospitals, hotels, offices and other noise-sensitive applications. Voltage 220V (or as requested), frequency 50/60Hz, electric start, ATS available.
Product Features
1. Canopy with acoustic foam, anti-vibration mounts and large silencer.
2. Service door for routine maintenance without removing the canopy.
3. AVR self-excited constant voltage, copper alternator, stable output.
4. Large fuel tank for long run time, with movable wheels.
5. Electric start; ATS automatic mains transfer available.
6. Voltage, frequency, sockets and panel customizable6. Voltage, frequency, sockets and panel customizable.
主要技术参数 / Main Specifications
|
项目 / Item |
PMD-6500S |
PMD-8500S |
PMD-12000S |
PMD-16000S |
|
额定输出Rated Output (kVA) |
5.0 |
8.0 |
9.5 |
12.0 |
|
最大输出Max. Output (kVA) |
5.5 |
8.8 |
11.0 |
13.0 |
|
发动机Engine Model |
186FA |
192F |
2V80 (Double-cylinder) |
292F (Double-cylinder) |
|
排量Displacement (ml) |
418 |
498 |
794 |
996 |
|
冷却方式Cooling |
风冷 Air-cooled |
水冷 Water-cooled |
风冷 Air-cooled |
|
|
额定电压 / Rated Voltage (V) |
110V/220V/380V/440V |
|||
|
频率 / Frequency (Hz) |
50 / 60 |
|||
|
额定转速 / Rated Speed (r/min) |
3000 / 3600 |
|||
|
相数 / Phase |
单相 Single-phase/三相 Th |
|||
|
功率因数 / Power Factor (cosΦ) |
1 |
|||
|
噪音 / Noise (dB(A)@7m) |
≤74 |
≤75 |
≤75 |
≤75 |
|
励磁方式 / Excitation |
自励恒压 AVR / Self-excited & Constant Voltage (AVR) |
|||
|
结构形式 / Structure |
静音罩式 / Silent (Canopy) Type |
|||
|
起动方式 / Starting |
电起动 Electric Start（可选 ATS / optional） |
|||
Remark: Models with bigger output up to 800kw gensets are also available.
