Product Profile
The 180/220 hammer head is the core wear part of hammer crushers (sand making machines), suspended on the rotor via pin shafts and rotating at high speed to crush materials through impact, shear and grinding. Widely compatible with small hammer crushers such as the 250×100 model, with 6 hammers per machine. Material options include high manganese steel, high chrome alloy or bimetal composite, selected based on material hardness and abrasiveness.
Product Features
1. Precision casting with dense structure, free from porosity and sand defects.
2. High manganese steel hammers work-harden under impact while retaining inner toughness — wear-resistant without fracture.
3. High chrome alloy hammers achieve HRC55-63 hardness with 3× the wear life of manganese steel.
4. Bimetal composite hammers combine both advantages: impact-resistant shank + ultra-wear-resistant head.
5. Precision pin hole positioning — direct replacement of worn parts without equipment modification.
6. Customization available per drawings; size and material can be tailored to customer crusher models.
主要技术参数 / Main Specifications
|
品名 Product name |
锤式破碎机锤头 / Hammer for Hammer Crusher |
|
|
规格型号 Model |
180 |
220 |
|
适配机型 Compatible crusher |
250×100 小型锤式破碎机 / Small hammer crusher |
中大型锤式破碎机 / Medium-large hammer crusher |
|
每台用量 Qty per machine |
6 pcs |
6–8 pcs |
|
材质 Material |
高锰钢 Mn13/Mn13Cr2 / 高铬合金 Cr26 / 双金属复合 / High Mn Steel, High Cr Alloy, Bimetal |
|
|
硬度 Hardness |
高锰钢 HB200–250（硬化后 HB450–550）；高铬 HRC55–63 / Mn steel HB200–250 (work-hardened HB450–550); Cr alloy HRC55–63 |
|
|
加工方式 Process |
精密铸造 / Precision casting |
|
|
安装方式 Installation |
销轴悬挂式 / Pin shaft suspension |
|
支持来图定制尺寸和材质 / Custom size and material available per customer drawings.
