Product Features:
Easy and quick start; Low fuel consumption; Miniature fuel injection system; Mature production technology; Support high intensity use; Wide application area.
Application Of Diesel Engine:
Agricultural machines: tillers, harvesters, ditchers, branch chipper, rice milling machines, water pumps etc. Construction machines: plate compactors, road rollers, road cutting machines, generators etc. Transportation machines: walking tractors, boats etc.
|
参数 Parameter |
2V88FE |
292FE |
295FE |
2V92FE |
2V95FE |
|
型式 Type |
双缸 V 型风冷四冲程 |
双缸 V 型风冷四冲程 V-twin air-cooled 4-stroke |
|||
|
缸径×行程 Bore×Stroke (mm) |
2-88×72 |
2-92×75 |
2-95×75 |
2-95×80 |
2-95×88 |
|
排量 Displacement (ml) |
875 |
996 |
1063 |
1064 |
1247 |
|
压缩比 Compression Ratio |
19:1 |
19:1 |
19:1 |
19:1 |
19:1 |
|
额定功率 Rated (kW/3000,3600rpm) |
13.0 / 14.0 |
13.5 / 14.5 |
14.5 / 15.0 |
14.8 / 15.3 |
19.0 / 19.0 |
|
最大功率 Max. (kW/3000,3600rpm) |
14.3 / 15.4 |
14.8 / 16.0 |
15.5 / 16.0 |
16.2 / 16.8 |
20.9 / 20.9 |
|
额定功率 Rated (HP/3000,3600rpm) |
17.6 / 19.0 |
18.4 / 19.7 |
18.4 / 19.7 |
20.1 / 20.8 |
25.8 / 25.8 |
|
最大扭矩 Max. Torque (N·m/r/min) |
51 / 2400 |
52 / 2400 |
57 / 2400 |
59 / 2400 |
66 / 2400 |
|
额定转速 Rated Speed (r/min) |
3000 / 3600 |
||||
|
润滑方式 Lubrication |
Pressure splash 压力飞溅复合式 |
||||
|
旋转方向 Rotation Direction |
Anticlockwise (Face to the output axle) 逆时针(面对输出轴) |
||||
|
燃油 Fuel |
0#(夏)/-10#(冬)/-35#(极寒) diesel 柴油 |
||||
|
燃油消耗 Fuel Consump. (g/kW·h) |
≤245 |
||||
|
机油等级 Lube Oil |
CD grade or SAE 10W-30, 15W-40 |
||||
|
机油容量 Lube Oil Cap. (L) |
3.2 |
3.8 |
3.8 |
3.8 |
4.0 |
|
噪音 Noise at 7m (dB) |
≤86 |
||||
|
启动方式 Start System |
Electric starter 电启动 |
||||
|
包装尺寸 Package (mm) |
670×490×580 |
630×630×670 |
630×630×670 |
660×750×710 |
660×750×710 |
|
毛重 Gross Weight (kg) |
77 |
87 |
87 |
96 |
96 |
